Hot Rolling Press with Asynchronous Speed for Dry Electrode / Solid State Electrolyte Fabrication (Max. 200mm W, 15T, 200 °C) - MSK-BPC-DF200

Hot Rolling Press with Asynchronous Speed for Dry Electrode / Solid State Electrolyte Fabrication (Max. 200mm W, 15T, 200 °C) - MSK-BPC-DF200

Minimum Order: $20 (equipment), $100 (crystals)

Price: RFQ

SKU:

Choose Your Variant or Type in Any Add-Ons:



View full details

MSK-BPC-DF200 is a three-roller continuous rolling press with various speeds to prepare a lithium-ion battery's dry electrode and solid-state electrolyte sheet. Three pairs of rolls can be independently controlled under a pressure of 8T Max.

SPECIFICATIONS:

Power
  •  AC220±10%, single phase, 50/60Hz
  • 5KW
Rollers
  • Roller materials: Hardening Cr12MoV
  • Roller size: Ø150 mm x 220 mm
  • Hardness: HRC 58-62
  • Roller Gap: 0 - 1.5 mm
  • Gap accuracy: +/- 2.5 um
Working Mechanism
Roller Temperature
  • 200°C Max.., each roller temperature can be adjusted independently.
Maximum Electrode Width
  •  180mm Max.
Rolling Pressure
  • 15T Max., each roller pressure can be adjusted independently. Applied force resolution: ±0.30Kg.
Rolling Speed
  • 0.3- 2 m/min, each roller speed can be adjusted independently.
Recommended Working Environment
  • 25 ± 3°C, no vibration or electromagnetic interference
Compliance
  • CE Certified
  • NRTL certification is available upon request at the extra cost
Application Note



×

Overall Dimensions:

  • 1200mm L x 680mm W x 1400mm H

Net weight:

  • 600 kg

MTI offers a One-Year limited warranty for this product.

The MTI One Year Limited Warranty does NOT cover

  • Consumable parts, such as graphite dies, O-rings, crucibles, screws, washers, glassware, etc.
  • Any damage and rust resulting from improper storage or maintenance.
  • Any damages caused by the use of corrosive and acidic gases.
  • Any damage resulting from failing to adhere to the individual product's specific operation requirements, such as water cooling, venting, etc.
Manufacturer Part Number:
