Heavy Duty Rolling Press (180Wx132D, mm ) w/ Variable Speed For Metallic Materials - MSK-5070-AC

Heavy Duty Rolling Press (180Wx132D, mm ) w/ Variable Speed For Metallic Materials - MSK-5070-AC

Low stock: 1 left

Price: RFQ

SKU: MSK5070AC

Choose your Variant:



View full details

MSK-5070-AC is a 180mm width ( 7.1 ") heavy-duty electric rolling press with 7.5 horsepower and variable speed, which is designed for rolling metallic material ( < Rc 50) up to 20 mm thickness, such as copper, stainless steel, Nickel alloy, etc.

SPECIFICATIONS:

Power / AC Converter
  • Input Voltage: 208- 240VAC Three Phase, 50/60Hz
  • 5.5KW Three Phase Motor ( 7.5 horsepower )
Rollers
  • Roller materials: Hardening Cr12MoV
  • Roller size: 132 mm dia. x 180 mm width (~ 5" Dia x 7" width )
  • Hardness: HRC 60-62
  • Rolling thickness: 0.02 - 20 mm adjustable
  • Gap accuracy: +/- 0.05 mm
  • Min. thickness is dependent on the materials. The below is based on our experience:
    • Ag: 0.06 mm
    • Au: 0.04 mm
    • Sn: 0.02 mm
    • Cu: 0.06 mm
Rolling Speed
  • 0 - 8 mm / second adjustable via Frequency control with constant output power.
  • The speed control unit is in separate box



Compliance
  • CE Certified
  • NRTL certification is available upon request at the extra cost.

Application Note
  • Never roll materials with hardness > 50HRC
  • The thickness of each time pressing is depending on material thickness. The harder material shall be less press thickness, which customers shall test by themselves for the best parameters
  • For some material that is easy work hardening, you may need to anneal it by furnace after each rolling.



×

Overall Dimension:

  • 1020 mm(L) x 730 mm (W) x 1400 mm (H)

Net weight:

  • 900kg

Shipping Weight & Dimensions:

  • 2250 lbs
  • 48" x 45" x 66"

MTI offers a One-Year limited warranty with lifetime support(may cause a fee) for this product.

The MTI One Year Limited Warranty does NOT cover

  • Consumable parts such as O-rings, crucibles, screws, washers, etc.
  • Any damage and rust resulting from improper storage or maintenance.
  • Any damages caused by the use of corrosive and acidic gases.
  • Any damage resulting from failing to adhere to the individual product's specific operation requirements, such as water cooling, venting, etc.
